Oxford Alloys Metallic Luster Er70s-6 Carbon Steel Bare Rod, 1/8 Inch Dia. X 36 Inch L 70S-61/8X36 OXF70S-61/8X36

Oxford Alloys® Metallic Luster ER70S-6 Carbon Steel Bare Rod, 1/8 Inch dia. x 36 Inch L

$20.18 / 10 lb tube
19% off list $25.02
Our Id: OXF70S-61/8X36
Manufacturer Id: 70S-61/8X36
102 in stock.
Check Store Inventory
Add To Cart

Detailed Description

Oxford Alloy ER70S-6 contains high levels of manganese and silicon for stronger deoxidizing power where stringent cleaning procedures are not possible. The high silicon content increases the fluidity of the weld pool, creating a smoother bead appearance and resulting in minimal post-weld grinding. The Oxford Alloy ER70S-6 has been designed to provide X-ray quality porosity-free welds and the highest tensile strength (as welded) of the plain carbon steel wires. This wire is excellent where poor fit-ups or rusty and oily plates may be used

Features
  • 100% argon shielding gas for TIG (GTAW)
  • 98% argon + 2% oxygen/75% argon + 25% Co2 shielding gas for MIG (GMAW) spray transfer
  • 100% Co2/75% argon + 25% Co2 shielding gas for MIG (GMAW) short circuiting transfer
  • 15 - 20 volt TIG (GTAW)

Oxford Alloys® 70S-61/8X36 Carbon Steel Bare Rod, Diameter: 1/8 Inch, Length: 36 Inch, Amperage: 175 - 250 amp TIG (GTAW), AWS Class: AWS 5.18: ER70S-6, Metallic Luster, Tensile Strength: 79750 psi, Yield Strength: 65250 psi, Elongation in 2" (%): 30%, Welding Process: TIG (GTAW)/MIG/SAW, Weld Metal Composition: 0.06 - 0.15% Carbon (C), 1.40 - 1.85% Manganese (Mn), 0.80 - 1.15% Silicon (Si), 0.025% Phosphorus (P), 0.035% Sulphur (S), 0.15% Nickel (Ni), 0.15% Chromium (Cr), 0.15% Molybdenum (Mo), 0.03% Vanadium (V), 0.50% Copper (Cu), Applicable Materials: Mild, Low Alloy Steel

Technical Details

Amperage
175 - 250 amp TIG (GTAW)
Applicable Materials
Mild, Low Alloy Steel
AWS Class
AWS 5.18: ER70S-6
Color
Metallic Luster
Diameter
1/8 Inch
Elongation in 2" (%)
30%
Length
36 Inch
Tensile Strength
79750 psi
Weld Metal Composition
0.06 - 0.15% Carbon (C), 1.40 - 1.85% Manganese (Mn), 0.80 - 1.15% Silicon (Si), 0.025% Phosphorus (P), 0.035% Sulphur (S), 0.15% Nickel (Ni), 0.15% Chromium (Cr), 0.15% Molybdenum (Mo), 0.03% Vanadium (V), 0.50% Copper (Cu)
Welding Process
TIG (GTAW)/MIG/SAW
Yield Strength
65250 psi
